Double Sided PET Tape
Introduce
Double Sided PET Tapes consist of an acrylic adhesive coated on both sides of a thin polyerster film(PET film).A release liner is added to one side. The aggressive acrylic adhesive provides high initial adhesion to a wide range of surfaces including wood, metal, paper and most plastics including polyethylene and polypropylene.
Features
• Excellent adhesion to most surfaces
• Flexible to conform to irregular surfaces
• Hand tearable
• High tack level offers high immediate adhesion
• Easily converted by die-cutting
• Dimensionally stable
Usage: Adhere laminating nameplate, foam material, membrane switch.
The double sided PET has good optical performance and is used in
making LCD screen frame, nameplate or fasteners
Double sided PET tape catalogues
Number |
Material |
Thick(mm) |
Color |
Peel adhesion(N\25MM) |
Temp |
983 |
PET |
0.03 |
clear |
≥9 |
100~150℃ |
972 |
PET |
0.05 |
clear |
≥8 |
100~150℃ |
980 |
PET |
0.08 |
clear |
≥10 |
100~150℃ |
982 |
PET |
0.1 |
clear |
≥12 |
100~150℃ |
928 |
PET |
0.125 |
clear |
≥14 |
100~150℃ |
967 |
PET |
0.16 |
clear |
≥16 |
100~150℃ |
965 |
PET |
0.205 |
clear |
≥18 |
100~150℃ |
970 |
PVC |
0.245 |
white |
≥18 |
100~150℃ |
968 |
PVC |
0.325 |
white |
≥20 |
100~150℃ |
