Enclosed EMI Materials
Composition:
Ni |
Cu |
Ni |
Water PU |
Properties
Item |
Unit |
Value |
Description |
|
|
|
|
Surface Resistance |
Ω/inch2 |
＜0.08 |
MIL G 83528 |
Vertical Resistance |
Ω/inch3 |
＜0.03 |
MIL G 83528 |
Shielding |
dB |
≥60 |
ASTM 4935 |
Effectiveness |
|||
|
|
|
|
|
|
|
|
Elongation |
% |
380±20 |
KS M 3014-96 |
|
|||
215±20 |
|||
|
|
|
|
|
|
|
|
Tensile strength |
kg/cm2 |
13.2±10 |
KS M 3014-96 |
|
|||
10.3±10 |
|||
|
|
|
|
|
|
|
|
Compressive |
% |
68.6 |
JIS K 6400 |
Restitutive Rate |
|||
|
|
|
|
|
|
|
|
Material Weight |
g/m2 |
208.7±5 |
ASTM D3776 |
Thickness |
mm |
0.5+0.30/-0mm |
FZ/T01003-1991 |
|
|
|
|
Color |
/ |
Gray Black |
Visual |
3. Work Temp Range
-40℃～70℃
4.Storage and shelf life ：
Keep in shade and cool place ,avoiding high Temp&humidity or sunshine( -20℃～40℃,≤65%RH), shelf life is 2 years.
Above data are the average value after test many times. Users are solely responsible for making preliminary tests to determine the suitability of products for their intended use.
There are many factors that can infect the characters in intended use. Please contact Eteng for more details. Thank you!
